Garrison Fencing Brackets

Garrison fencing brackets are the critical link between steel posts and fence panels, ensuring a rigid, tamper-resistant connection that stands up to wind loads, vibration, and attempted intrusion. Manufactured from 2 mm wall-thickness steel and available with either hot-dip galvanization or a durable polyester powder coat, these brackets deliver both strength and corrosion resistance for decades of reliable service.Materials & Finishes

• Steel Construction: 2 mm wall thickness provides a balance of rigidity and form-ability.

• Garrison fencing brackets  Corrosion Protection:

• Hot-Dip Galvanized under ASTM A123 for complete zinc encapsulation.

  • Polyester Powder Coat applied over galvanization (optional) for added weather resistance and a uniform finish.

Bracket Designs & Specifications Garrison fencing brackets

• Bracket A & B: 90 mm long for added leverage; B is 10 mm taller to accommodate thicker rails or decorative panels.

• Bracket C & D: 75 mm long for compact installations; D adds two extra holes for increased pull-out resistance under high loads.

Performance & Applications Garrison fencing brackets

1. Security Fencing

   • Rigid attachment prevents panel rotation or prying.

   • Galvanized finish resists forced entry tools and environmental attack.

2. Industrial & Commercial

   • Chemical-resistant powder coat suits manufacturing or coastal sites.

   • Multiple hole patterns enable staggered fixing for uneven substrates.

3. Residential & Landscape

   • Slim profiles on C and D brackets minimize visual impact.

   • Choice of finishes allows colour matching with gates and accessories.

Installation Tips Garrison fencing brackets

• Fastener Selection: Use 6 mm stainless-steel or high-tensile screws to match hole diameter and ensure corrosion resistance.

• Torque Settings: Tighten to just snug—over-torquing can deform the bracket or strip powder-coat protection.

• Alignment: Pre-mark post face and panel edge to ensure each bracket sits square, avoiding panel twist.

Choosing the Right Bracket

• Bracket A: Standard installations where panel height is typical (25 mm rail thickness).

• Bracket B: Taller mounting flange for thicker or decorative rails.

• Bracket C: Space-constrained zones or flush-mount aesthetic.

• Bracket D: High-stress areas (gates, wind-loaded stretches) requiring extra screw retention.

Conclusion Garrison fencing brackets

Whether securing a high-security perimeter or installing a decorative boundary fence, Garrison fencing brackets (A–D) offer a straightforward, durable solution. Their steel construction, versatile sizing, and choice of finishes mean you can tailor every installation for maximum performance with minimal fuss.
